Description
About the Trail Neo 3
An e-mountain bike that will raise your game and ignite a passion for the trail
Where it thrives: Low-impact trails, up and down hills
What it’s built for: Speed, efficiency, handling
Key Features
- Lightweight SmartForm C1 Alloy frame, dual battery ready / SR Suntour XCM 34 Boost 100mm fork
- Shimano Deore 10-speed drivetrain / hydraulic disc brakes
- Bosch Performance Line CX drive unit / 500Wh battery / Range: up to 114km
Specifications
Frameset
- Frame: SmartForm C1 Alloy, Dual Battery ready, removable downtube battery, SAVE, tapered headtube, internal cable routing, Ai offset drivetrain, 148x12mm thru-axle, post mount disc, KickFlip hidden kickstand mount, skid plate, rack/fender mounts
- Fork: SR Suntour XCM 34 Boost, 100mm, Coil, 46mm offset
Wheels
- Rims: WTB STX i25 TCS, 32h, tubeless ready
- Hubs: (F) Shimano MT400, 15x110mm thru-axle (R) Shimano MT400, 12x148mm thru-axle
- Tyres: Maxxis Ardent, 27.5/29 x 2.4, Wire 60TPI Exo
Drivetrain
- Pedals: Not included
- Front Derailleur: N/A
- Rear Derailleur: Shimano Deore M4100
- Shifters: Shimano Deore M4100, 10-speed
- Chain: Shimano HG54, 10-Speed
- Crankset: FSA Bosch E-Bike w/ custom Ai offset, 34T
- Rear Cogs: Shimano Deore, 11-42, 10-Speed
Components
- Handlebar: Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
- Stem: Cannondale 3, 6061 Alloy, 31.8, 0°
- Brakes: Shimano MT200 hydraulic disc, 180mm RT10 rotors
- Brake Levers: Shimano MT200 hydraulic disc
- Saddle: Cannondale Ergo XC
- Seatpost: Cannondale 4, 6061 Alloy, 31.6 x 350mm
E-System
- Drive Unit: Bosch Performance Line CX
- Battery: Bosch Powertube 500Wh
- Charger: Bosch 2A
- Display: Bosch Purion
Bike Sizing
| S | M | L | XL | |
|---|---|---|---|---|
| Rider Height | 5’4 – 5’8 / 162cm – 172cm | 5’7 – 6’0 / 170cm – 182cm | 6’0 – 6’3 / 182cm – 190cm | 6’4 – 6’8 / 193cm – 203cm |
Product code: 713362
